| serial number | product name | Thailand specification model | outer diameter/mm | wall thickness/mm | densitykg/m3 | Vika℃ | Lead limit（mg/kg） | Ash content/600℃% | Remark | Metric outer diameter dimensions/mm | Metric Thickness Dimensions/mm |
| 20240222001 | Thai standard line pipe-yellow | 15（3/8"） | 17.87-17.92 | 1.51-1.74 | 1539 | 81.6 | ND | 31.6 | 1) Lead-free formula, does not contain lead; 2) There are approximately 30 parts of calcium added to 100 PVC resin powder; |
∅18.0 | 1.50±0.15 |
| 18（1/2"） | 21.86-22.01 | 1.24-1.52 | 1569 | ∅22.0 | 1.50±0.15 | ||||||
| 20（3/4"） | 25.9-26.04 | 1.58-1.64 | 1570 | ∅26.0 | 1.60±0.15 | ||||||
| 25（1"） | 33.96-34.10 | 1.81-2.06 | 1561 | ∅34.0 | 2.00±0.15 |
1) Lead-free formula, does not contain lead;
2) There are approximately 30 parts of calcium added to 100 PVC resin powder;
PVC-U is a flame retardant thermoplastic with exceptional chemical resistance and low stress cracking. PVC-U shows high mechanical strength for continuous operating between -15 °C and +60 °C. Good mechanical properties. Exceptional chemical resistance. Compared with metal pipes, PVC pipes have absolute advantages, light weight, low transportation costs, easy installation, corrosion resistance, no rust, low maintenance costs, and stable chemical properties. At the same time, the production cost of PVC pipes is low, and it is a cost-effective pipe material, which is suitable for daily residents. This pipe is recyclable and friendly to the environment. HOMSO has 7 production bases in China, and manufactur following sizes pipes:
We also support OEM and ODM service. If you are interested in other sizes pipe or standards or self-brand, please let me know. We are so glad to satisfy your puchase requirements.
Schedule 40: For Normal duty applications (Underground Use)
Schedule 80: For Heavy duty applications (Industrial, Above & Underground Use)
